TILT FRAME [305692-26]
Parts (20)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 416-00170 Frame, Cargo Box | Frame, Cargo Box | 1 | — | Obsolete | View Details |
| 2 | 9506-544 Latch, Tilt | Latch, Tilt | 1 | $106.95 | Out of Stock | Notify Me |
| 3 | 2416-404 Spring, Latch | Spring, Latch Right | 1 | $16.09 | Out of Stock | Notify Me |
| 3 | 2416-405 Spring, Latch | Spring, Latch Left | 1 | $16.09 | Available to order | 1 |
| 4 | 8408-845 Screw, Cap | Screw, Cap | 3 | $1.23 | Available to order | 3 |
| 5 | 1406-674 Half, Clamp | Half, Clamp | 6 | $2.29 | Available to order | 6 |
| 6 | 5406-160 SPACER,19X11X4 Z&C | SPACER,19X11X4 Z&C | 3 | $1.23 | Available to order | 3 |
| 7 | 8427-802 Nut, Lock | Nut, Lock | 3 | $0.61 | Available to order | 3 |
| 8 | 1406-736 Grip, Latch | Grip, Latch | 2 | $4.49 | Available to order | 2 |
| 9 | 0423-355 Screw, Shoulder | Screw, Shoulder | 4 | $1.12 | Available to order | 4 |
| 10 | 7406-050 Bumper, Tilt Frame | Bumper, Tilt Frame | 2 | $11.69 | Available to order | 2 |
| 11 | 0623-038 Nut | Nut | 8 | $0.40 | Available to order | 8 |
| 12 | 6406-797 Bracket, Tie Down - Lower | Bracket, Tie Down - Lower | 2 | $5.49 | Available to order | 2 |
| 13 | 0405-640 Spring, Gas | Spring, Gas | 1 | $29.95 | Available to order | 1 |
| 14 | 5406-597 Bracket, Electric Lift | Bracket, Electric Lift | 1 | $37.95 | Available to order | 1 |
| 15 | 8468-617 Screw, Machine | Screw, Machine | 2 | $0.61 | Available to order | 2 |
| 16 | 1423-596 Screw, Cap | Screw, Cap | 1 | $12.49 | Available to order | 1 |
| 18 | 9406-010 Wear Pad, Box Latch - Right | Wear Pad, Box Latch - Right | 1 | $2.59 | Available to order | 1 |
| 18 | 9406-011 Wear Pad, Box Latch - Left | Wear Pad, Box Latch - Left | 1 | $2.59 | Out of Stock | Notify Me |
| 19 | 1623-661 Screw, Self-Tapping | Screw, Self-Tapping | 2 | $2.79 | Available to order | 2 |
