F13-1-A — FRONT SEAT(NON HEATING EQUIPMENT)
Parts (23)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 01 | 30102-080045170 SCREW | SCREW | 6 | $2.29 | Available to order | 6 |
| 02 | 7020-130001 RUBBER SLEEVE, SEAT | RUBBER SLEEVE, SEAT | 1 | $5.74 | Available to order | 1 |
| 03 | 5HY0-132004 CUSHION, RUBBER WASHER | CUSHION, RUBBER WASHER | 1 | $3.44 | Available to order | 1 |
| 04 | 5HY0-132000-40000 PASSENGER SEAT | PASSENGER SEAT | 1 | $549.99 | Out of Stock | Notify Me |
| 05 | 5HYV-134000-1C00 BACKREST | BACKREST | 1 | $131.99 | Available to order | 1 |
| 06 | 30904-080A220 PIN SHAFT | PIN SHAFT | 1 | $28.74 | Available to order | 1 |
| 07 | 30910-0183220 LOCK PIN | LOCK PIN | 6 | $5.74 | Available to order | 6 |
| 08 | 9030-131001 RUBBER CUSHION | RUBBER CUSHION | 1 | $1.25 | Available to order | 1 |
| 09 | 7020-140002 TIE BAND, RACK COVER | TIE BAND, RACK COVER | 1 | $12.64 | Available to order | 1 |
| 10 | 30006-060016870 BOLT M6x16 | BOLT M6x16 | 6 | $1.25 | Available to order | 6 |
| 11 | 5HY#-130002-1000 BACKREST DAMPING MAT | BACKREST DAMPING MAT | 2 | $2.29 | Available to order | 2 |
| 12 | 5HY#-133001-1000 REAR BRACKET | REAR BRACKET | 1 | $11.49 | Available to order | 1 |
| 13 | 5HY#-133000-1000 BACKREST ASSY | BACKREST ASSY | 1 | $296.99 | Available to order | 1 |
| 14 | 30306-080870 WASHER | WASHER | 6 | — | Obsolete | View Details |
| 15 | 5HY0-131140 SEAT LOCK | SEAT LOCK | 1 | $91.99 | Available to order | 1 |
| 16 | 5HY0-131000-50000 DRIVER SEAT ASSY | DRIVER SEAT ASSY | 1 | $769.99 | Out of Stock | Notify Me |
| 17 | 5HY0-131300-10000 MAIN BACKREST | MAIN BACKREST | 1 | $153.99 | Available to order | 1 |
| 18 | 30102-080016170 SCREW M8x16 | SCREW M8x16 | 1 | $1.25 | Available to order | 1 |
| 19 | 5HY0-131200-10000 DRIVER SEAT CUSHION | DRIVER SEAT CUSHION | 1 | $329.99 | Available to order | 1 |
| 20 | 5HY0-131010 SEAT FRAME | SEAT FRAME | 1 | $91.99 | Available to order | 1 |
| 21 | 5HY0-131100-10000 BOTTOM BRACKET,DRIVER SEAT | BOTTOM BRACKET,DRIVER SEAT | 1 | $318.99 | Out of Stock | Notify Me |
| 22 | 30003-060035810 BOLT | BOLT | 6 | $1.25 | Available to order | 6 |
| 23 | 6KM0-130205 RUBBER BUMPER | RUBBER BUMPER | 1 | $5.74 | Available to order | 1 |
