F13 — SEAT
Parts (22)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 01 | 5ASV-133000-6001 PASSENGER BACKREST ASSY | PASSENGER BACKREST ASSY | 1 | — | Obsolete | View Details |
| 02 | 5HY#-133001-1000 REAR BRACKET | REAR BRACKET | 1 | $11.49 | Available to order | 1 |
| 03 | 30006-060016870 BOLT M6x16 | BOLT M6x16 M6x16 | 6 | $1.25 | Available to order | 6 |
| 04 | 5ASV-132000-6001 PASSENGER SEAT ASSY | PASSENGER SEAT ASSY | 1 | $329.99 | Obsolete | View Details |
| 05 | 6KM0-130205 RUBBER BUMPER | RUBBER BUMPER | 1 | $5.74 | Available to order | 1 |
| 06 | 7020-130001 RUBBER SLEEVE, SEAT | RUBBER SLEEVE, SEAT | 1 | $5.74 | Available to order | 1 |
| 07 | 5ASV-132000-6000-23 DAMPING RUBBER, SEAT | DAMPING RUBBER, SEAT | 1 | $8.04 | Available to order | 1 |
| 08 | 5HY#-130002-1000 BACKREST DAMPING MAT | BACKREST DAMPING MAT | 2 | $2.29 | Available to order | 2 |
| 09 | 5ASV-131000-6002 DRIVER SEAT ASSY | DRIVER SEAT ASSY | 1 | $549.99 | Out of Stock | Notify Me |
| 10 | 5ASV-131300-6000 DRIVERS SEAT, BACK CUSHION | DRIVERS SEAT, BACK CUSHION | 1 | $329.99 | Available to order | 1 |
| 11 | 5ASV-131500-6000 DRIVERS SEAT CUSHION | DRIVERS SEAT CUSHION | 1 | $329.99 | Available to order | 1 |
| 12 | 30102-080016810 INNER HEX BOLT | INNER HEX BOLT | 6 | $1.25 | Available to order | 6 |
| 13 | 5ASV-131200-6000 SEAT FRAME | SEAT FRAME | 1 | $197.99 | Out of Stock | Notify Me |
| 14 | 30204-080810 LOCK NUT | LOCK NUT M8 | 6 | $1.25 | Available to order | 6 |
| 15 | 5ASV-131100-6001 BRACKET, DRIVER SEAT | BRACKET, DRIVER SEAT | 1 | $230.99 | Available to order | 1 |
| 16 | 5HY0-131140 SEAT LOCK | SEAT LOCK | 1 | $91.99 | Available to order | 1 |
| 17 | 30003-060035810 BOLT | BOLT | 6 | $1.25 | Available to order | 6 |
| 18 | 8030-130211 DAMPER, FRONT SEAT | DAMPER, FRONT SEAT | 6 | $2.29 | Available to order | 6 |
| 19 | 5ASV-134000-6000 HEAD REST | HEAD REST | 1 | $142.99 | Available to order | 1 |
| 20 | 5HY#-040001-1000 BOLT M6x14 | BOLT M6x14 | 6 | $1.25 | Available to order | 6 |
| 21 | 5ASV-131600-6000 HANDLE, SLIDE TO UNLOCK | HANDLE, SLIDE TO UNLOCK | 1 | $10.34 | Available to order | 1 |
| 22 | 30006-050012870 BOLT | BOLT | 6 | $1.25 | Available to order | 6 |
