F15-1-A — ELECTRIC SYSTEM(NA)
Parts (40)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 01 | 9CSV-150100-A201 MAIN CABLE | MAIN CABLE | 1 | $1099.99 | Available to order | 1 |
| 02 | 9010-150350 AUXILIARY RELAY | AUXILIARY RELAY | 1 | $12.64 | Available to order | 1 |
| 03 | 5BY4-150330 RELAY, SMALL | RELAY, SMALL | 1 | $12.64 | Available to order | 1 |
| 04 | 806A-151305 FUSE (15A) | FUSE (15A) 15A | 2 | $2.29 | Available to order | 2 |
| 05 | 806A-151302 FUSE (10A) | FUSE (10A) 10A | 2 | $3.44 | Available to order | 2 |
| 06 | 8010-150003 TIE BAND | TIE BAND 5x250 | 6 | $1.25 | Available to order | 6 |
| 07 | 9DS#-150009-6100-M1 TIE BAND | TIE BAND | 1 | $2.29 | Available to order | 1 |
| 08 | 7030-150005 TIE BAND | TIE BAND | 6 | $3.44 | Available to order | 6 |
| 09 | 0180-014010 WIRE CLAMP | WIRE CLAMP | 6 | — | Obsolete | View Details |
| 10 | 5020-150700 ELECTRIC HORN | ELECTRIC HORN | 1 | $22.99 | Obsolete | View Details |
| 11 | 30006-080014810 BOLT M8X14 | BOLT M8X14 M8x14 | 6 | $1.25 | Available to order | 6 |
| 12 | 9DSV-001000-5001 ECU | ECU | 1 | $769.99 | Available to order | 1 |
| 13 | 30006-060030810 BOLT M6x30 | BOLT M6x30 M6x30 | 6 | $1.25 | Available to order | 6 |
| 14 | 30006-060025810 BOLT | BOLT M6x25 | 6 | $3.44 | Available to order | 6 |
| 15 | 018B-178000 IGNITION COIL | IGNITION COIL | 1 | $114.99 | Available to order | 1 |
| 16 | 0GSV-178000-3000 HIGH-TENSION CABLE | HIGH-TENSION CABLE | 1 | — | Obsolete | View Details |
| 17 | 9CR6-150310 STARTER RELAY | STARTER RELAY | 1 | $45.99 | Available to order | 1 |
| 18 | 806A-151308 30A FUSE | 30A FUSE | 1 | $1.60 | Available to order | 1 |
| 19 | 9DS#-150210-6000 NEGATIVE WIRE, BATTERY | NEGATIVE WIRE, BATTERY | 1 | $34.49 | Available to order | 1 |
| 20 | 9DS#-150230-6002 POSITIVE WIRE, BATTERY | POSITIVE WIRE, BATTERY | 1 | $34.49 | Available to order | 1 |
| 21 | 31023004 BATTERY, Dynavolt 12v30ah | BATTERY, Dynavolt 12v30ah DYNAVOLT,12V30Ah | 1 | $186.99 | Out of Stock | Notify Me |
| 22 | 9060-152100 BATTERY STRAP | BATTERY STRAP | 1 | $10.34 | Available to order | 1 |
| 23 | 9DSV-150600-6R01 USB OUTLET SOCKET | USB OUTLET SOCKET | 1 | — | Obsolete | View Details |
| 24 | 9DSV-150500-6R01 POWER OUTLET SOCKET | POWER OUTLET SOCKET | 1 | $45.99 | Available to order | 1 |
| 25 | 30105-050030410 SCREW M5x30 | SCREW M5x30 M5x30 | 6 | $1.25 | Available to order | 6 |
| 26 | 9DQV-151300-3100 POWER SOCKET, TRAILER | POWER SOCKET, TRAILER | 1 | $80.49 | Available to order | 1 |
| 27 | 9DSV-151000-4000 REGULATOR | REGULATOR | 1 | $219.99 | Available to order | 1 |
| 29 | 9DS#-030501-6000 MOUNTING PLATE,FUSE BOX | MOUNTING PLATE,FUSE BOX | 1 | $6.89 | Available to order | 1 |
| 30 | 30110-421130010 SELF TAPPING SCREW | SELF TAPPING SCREW ST4.2x13 | 6 | $3.44 | Available to order | 6 |
| 31 | 5BY0-150305 CAP, DIAGNOSIS CONNECTOR | CAP, DIAGNOSIS CONNECTOR | 1 | $3.44 | Available to order | 1 |
| 32 | 9CR6-103501 FUSE (40A) | FUSE (40A) 40A | 1 | $9.19 | Available to order | 1 |
| 33 | CFCV-156103-2000 PLUG, T-BOX CONNECTOR | PLUG, T-BOX CONNECTOR | 1 | $11.49 | Available to order | 1 |
| 35 | 6KMV-150901-B001 RUBBER RING, T-BOX | RUBBER RING, T-BOX | 1 | $2.29 | Obsolete | View Details |
| 36 | CFC#-150008-4500 FUSE 50A | FUSE 50A | 1 | $3.44 | Available to order | 1 |
| 37 | 9CS#-150220-6701 CABLE, STARTER MOTOR | CABLE, STARTER MOTOR | 1 | $45.99 | Available to order | 1 |
| 38 | 9CS#-150250-6700 NEGATIVE CABLE, STARTER MOTOR | NEGATIVE CABLE, STARTER MOTOR | 1 | $25.29 | Available to order | 1 |
| 39 | 9DSV-161000-A100 FLASHER | FLASHER | 1 | $42.54 | Obsolete | View Details |
| 40 | 5BWV-040008-5000 INNER HEX BOLT M6x20 | INNER HEX BOLT M6x20 M6x20 | 2 | $1.25 | Available to order | 2 |
| 41 | 9GQA-030010-20000 BRACKET, STEPPER MOTOR | BRACKET, STEPPER MOTOR | 1 | $8.04 | Available to order | 1 |
| 42 | 5HYV-150191-2900 ADAPTOR CABLE, HORN | ADAPTOR CABLE, HORN | 1 | — | Obsolete | View Details |
