E01-1 — LEFT CRANKCASE ASSY
Parts (19)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 01 | 01A0-011001-0020 CYLINDER STUD | CYLINDER STUD | 1 | $5.74 | Obsolete | View Details |
| 02 | 01A0-0111A0 LEFT CRANKCASE COMP. | LEFT CRANKCASE COMP. RED | 1 | $307.99 | Obsolete | View Details |
| 02 | 01A0-0111A1 LEFT CRANKCASE COMP. | LEFT CRANKCASE COMP. BLUE | 1 | $307.99 | Obsolete | View Details |
| 03 | 30499-02504 BEARING 6205 | BEARING 6205 | 1 | $40.24 | Obsolete | View Details |
| 04 | 30499-01500 BEARING 6202 | BEARING 6202 | 1 | $19.54 | Available to order | 1 |
| 05 | 30499-02000 BEARING 6304 | BEARING 6304 | 1 | $45.99 | Obsolete | View Details |
| 06 | 0010-021005 DOWEL PIN f 10x14 | DOWEL PIN f 10x14 | 6 | $1.25 | Available to order | 6 |
| 07 | 0010-021014 WASHER 12 | WASHER 12 | 6 | $1.25 | Available to order | 6 |
| 08 | 0110-013005-0030 DRAIN BOLT, M12×1.5 | DRAIN BOLT, M12×1.5 | 6 | $3.44 | Obsolete | View Details |
| 09 | 0010-011010-0050 OUTER BUSH, ENGINE HANGER | OUTER BUSH, ENGINE HANGER | 1 | $5.74 | Obsolete | View Details |
| 10 | 0010-011008 O-RING, 15.8X2.4 | O-RING, 15.8X2.4 | 2 | $1.25 | Available to order | 2 |
| 11 | 01A0-011002-0050 INNER BUSH, ENGINE HANGER | INNER BUSH, ENGINE HANGER | 1 | $5.74 | Obsolete | View Details |
| 12 | 0030-011007-0030 BOLT M8x55 | BOLT M8x55 | 6 | $2.29 | Obsolete | View Details |
| 13 | 01A0-011300 OIL SEAL 25x35x5 | OIL SEAL 25x35x5 | 2 | $6.89 | Obsolete | View Details |
| 14 | 0010-060010 WASHER 10 | WASHER 10 | 6 | $3.44 | Available to order | 6 |
| 15 | 0010-060011-0030 RETAINER D22 | RETAINER D22 M10?1.25 | 6 | $1.14 | Obsolete | View Details |
| 16 | 01A0-011003 NOZZLE | NOZZLE | 1 | $2.29 | Available to order | 1 |
| 17 | 01A0-0111B1 PLAIN BEARING, LEFT CRANKCASE | PLAIN BEARING, LEFT CRANKCASE RED | 1 | $34.49 | Obsolete | View Details |
| 17 | 01A0-0111B2 PLAIN BEARING, LEFT CRANKCASE | PLAIN BEARING, LEFT CRANKCASE BLUE | 1 | $34.49 | Obsolete | View Details |
