E08 — WATER PUMP
Parts (24)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 01 | 0180-013208-0010 BOLT M6x45 | BOLT M6x45 | 6 | $1.25 | Available to order | 6 |
| 02 | 01A0-081000-1000 WATER PUMP ASSY | WATER PUMP ASSY | 1 | $120.99 | Obsolete | View Details |
| 03 | 0010-021019-0030 BOLT M6x12 | BOLT M6x12 | 6 | — | Obsolete | View Details |
| 04 | 0010-080013-0010 BOLT M6x22 | BOLT M6x22 | 6 | $1.25 | Available to order | 6 |
| 05 | 0010-060009 WASHER 6 | WASHER 6 | 6 | $1.25 | Available to order | 6 |
| 06 | 01A0-081002-0080 WATER PUMP HOUSING | WATER PUMP HOUSING | 1 | $28.74 | Obsolete | View Details |
| 07 | 0010-023008-00001 BOLT | BOLT | 6 | $1.25 | Available to order | 6 |
| 08 | 0010-080011 WASHER 6x12x1 | WASHER 6x12x1 | 6 | $1.25 | Available to order | 6 |
| 09 | 0A70-081102 IMPELLER, WATER PUMP | IMPELLER, WATER PUMP | 1 | $8.04 | Obsolete | View Details |
| 10 | 01A0-081101-1000 SHAFT, WATER PUMP | SHAFT, WATER PUMP | 1 | $6.89 | Obsolete | View Details |
| 11 | 01A0-081003 GASKET, WATER PUMP HOUSING | GASKET, WATER PUMP HOUSING | 1 | $1.14 | Obsolete | View Details |
| 12 | 0700-081200 WATER SEAL ASSY. | WATER SEAL ASSY. | 1 | $57.49 | Available to order | 1 |
| 13 | 01A0-081001 WATER PUMP BODY | WATER PUMP BODY | 1 | $28.74 | Obsolete | View Details |
| 14 | 0110-080005 OIL SEAL 10x20x5 | OIL SEAL 10x20x5 | 1 | $3.44 | Available to order | 1 |
| 15 | 0180-080002 O-RING 34x2.5 | O-RING 34x2.5 | 2 | $1.25 | Available to order | 2 |
| 16 | 30400-01000 BEARING 6000 | BEARING 6000 | 1 | $11.49 | Available to order | 1 |
| 17 | 30801-01005 RETAINER 10 | RETAINER 10 | 6 | $2.29 | Available to order | 6 |
| 18 | 0180-023500-0030 CLAMP, WATER HOSE | CLAMP, WATER HOSE | 1 | $4.59 | Obsolete | View Details |
| 19 | 01A0-080003 WATER OUTLET PIPE | WATER OUTLET PIPE | 1 | $22.99 | Obsolete | View Details |
| 20 | 30802-00603 CIRCLIP 6 | CIRCLIP 6 | 6 | $1.25 | Available to order | 6 |
| 21 | 01A0-070004 WASHER 8x16x1 | WASHER 8x16x1 | 6 | $1.14 | Obsolete | View Details |
| 22 | 01A0-080001 GEAR,WATER PUMP | GEAR,WATER PUMP | 1 | $5.74 | Obsolete | View Details |
| 23 | 30406-00300 NEEDLE P 3x21.8 | NEEDLE P 3x21.8 | 6 | $2.29 | Available to order | 6 |
| 24 | 01A0-080002-0050 SHAFT, WATER PUMP | SHAFT, WATER PUMP | 1 | $14.94 | Obsolete | View Details |
