F03-2 — MAIN FRAME
Parts (27)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 01 | 30006-080016810 BOLT M8X16 | BOLT M8X16 | 6 | $1.25 | Available to order | 6 |
| 02 | 6WWV-030040-5000 RH MIDDLE BRACKET, FRONT BUMPER | RH MIDDLE BRACKET, FRONT BUMPER | 1 | $28.74 | Available to order | 1 |
| 03 | 30006-060022810 BOLT M6X22 | BOLT M6X22 | 6 | $1.25 | Available to order | 6 |
| 04 | 9060-180029 RUBBER CUSHION TUBE, RADIATOR | RUBBER CUSHION TUBE, RADIATOR | 2 | $2.29 | Available to order | 2 |
| 05 | 6KM#-181001-8001 DAMPING RUBBER MAT | DAMPING RUBBER MAT | 1 | $3.44 | Available to order | 1 |
| 06 | 6WWV-0310B0-5002-0BP00 FRAME | FRAME | 1 | — | Obsolete | View Details |
| 07 | 6WWV-030011-5000 INNER HEX SCREW M10x46 | INNER HEX SCREW M10x46 | 6 | $2.29 | Available to order | 6 |
| 08 | 6WWV-030013-5000 INNER HEX SCREW M8x16 | INNER HEX SCREW M8x16 M8X16 | 6 | $2.29 | Out of Stock | Notify Me |
| 09 | 6WWV-030060-5000 RH REAR BRACKET, BUMPER | RH REAR BRACKET, BUMPER | 1 | $16.09 | Available to order | 1 |
| 10 | 6WWV-030050-5000 LH REAR BRACKET, BUMPER | LH REAR BRACKET, BUMPER | 1 | $16.09 | Available to order | 1 |
| 11 | 30006-080028810 BOLT M8x28 | BOLT M8x28 M8x28 | 6 | $1.25 | Available to order | 6 |
| 12 | 6WWV-000120-5000 RH BRACKET ASSY, GUARD | RH BRACKET ASSY, GUARD | 1 | $11.49 | Available to order | 1 |
| 13 | 6WWV-030090-5000 RH BRACKET, MIDDLE SUPPORTER | RH BRACKET, MIDDLE SUPPORTER | 1 | $103.49 | Out of Stock | Notify Me |
| 14 | K-54310086100 SELF LOCKING NUT M10 CU WS=15 | SELF LOCKING NUT M10 CU WS=15 | 2 | $5.75 | Available to order | 2 |
| 15 | 30006-050012810 BOLT | BOLT | 6 | $5.74 | Available to order | 6 |
| 16 | 0180-014010 WIRE CLAMP | WIRE CLAMP | 6 | — | Obsolete | View Details |
| 17 | 6WWV-030080-5000 LH, BRACKET | LH, BRACKET | 1 | $103.49 | Out of Stock | Notify Me |
| 18 | 6WWV-030017-5000 INNER HEX SCREW M10x30 | INNER HEX SCREW M10x30 | 6 | $2.29 | Available to order | 6 |
| 19 | 6WWV-030003-5000 BRACKET, SIDE STAND SWITCH CABLE | BRACKET, SIDE STAND SWITCH CABLE | 1 | $6.89 | Out of Stock | Notify Me |
| 20 | 6L30-030091 BOLT M10x60 | BOLT M10x60 M10x60 | 1 | $4.59 | Out of Stock | Notify Me |
| 21 | 6WWV-030009-5000 ENGINE HANGING BRACKET | ENGINE HANGING BRACKET | 1 | $80.49 | Out of Stock | Notify Me |
| 22 | 6WWV-030018-5000 BOLT M12x61 | BOLT M12x61 | 1 | $4.59 | Out of Stock | Notify Me |
| 23 | 30102-080050810 INNER HEX SCREW M8x50 | INNER HEX SCREW M8x50 | 6 | $1.25 | Available to order | 6 |
| 24 | 6WWV-030030-5000 LH MIDDLE BRACKET, FRONT BUMPER | LH MIDDLE BRACKET, FRONT BUMPER | 1 | $29.89 | Available to order | 1 |
| 25 | 6WWV-030001-5000 BRACKET, 6D SENSOR | BRACKET, 6D SENSOR | 1 | $9.19 | Out of Stock | Notify Me |
| 26 | 6WWV-030019-5000 RUBBER BUSHING | RUBBER BUSHING | 2 | $1.25 | Out of Stock | Notify Me |
| 27 | 6WWV-046902-5000 INNER HEX SCREW M6x20 | INNER HEX SCREW M6x20 | 6 | $1.25 | Out of Stock | Notify Me |
