F05 — FRONT SUSPENSION
Parts (25)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 01 | 9010-050600 FRONT SHOCK ABSORBER | FRONT SHOCK ABSORBER | 1 | $131.99 | Available to order | 1 |
| 02 | 30204-102810 NUT M10x1.25 | NUT M10x1.25 | 6 | $1.25 | Available to order | 6 |
| 03 | 7020-050200 FRONT UPPER A ARM, RH | FRONT UPPER A ARM, RH | 1 | $103.49 | Obsolete | View Details |
| 04 | 30801-03405 RETAINER 34 | RETAINER 34 | 6 | $1.25 | Available to order | 6 |
| 05 | 9010-050700-1000 TOP BALL PIN | TOP BALL PIN | 1 | — | Obsolete | View Details |
| 06 | 7020-050801 STEERING KNUCKLE, RH | STEERING KNUCKLE, RH | 1 | $91.99 | Available to order | 1 |
| 07 | 30800-05505 RETAINER 55 | RETAINER 55 | 6 | $2.29 | Available to order | 6 |
| 08 | 7020-050005 BRAKE DISC SHIELD | BRAKE DISC SHIELD | 1 | $19.54 | Available to order | 1 |
| 09 | 30006-060012870 BOLT M6x12 | BOLT M6x12 | 6 | $1.25 | Available to order | 6 |
| 10 | 9GQ0-050710 BEARING, HUB | BEARING, HUB | 1 | $57.49 | Available to order | 1 |
| 11 | 9010-300002 WASHER F10 | WASHER F10 | 6 | $1.25 | Available to order | 6 |
| 12 | 9DSV-050410-6K01-0BP00 FRONT RH LOWER SWING ARM | FRONT RH LOWER SWING ARM | 1 | $103.49 | Available to order | 1 |
| 13 | 9010-050800-20000 BOTTOM BALL PIN | BOTTOM BALL PIN | 1 | $57.49 | Available to order | 1 |
| 14 | 9010-050500 BUFFERING COLLAR | BUFFERING COLLAR | 4 | $8.04 | Available to order | 4 |
| 15 | 9010-050003 CAP, BUFFERING COLLAR | CAP, BUFFERING COLLAR | 2 | $3.44 | Obsolete | View Details |
| 16 | 901B-040024 RIGHT PROTECTOR, FRONT SUSPENSION | RIGHT PROTECTOR, FRONT SUSPENSION | 1 | $19.54 | Out of Stock | Notify Me |
| 17 | 8030-040800-00001 NUT CLIP M6 | NUT CLIP M6 | 6 | $2.29 | Available to order | 6 |
| 18 | 30006-102070810 BOLT | BOLT | 6 | $2.29 | Available to order | 6 |
| 19 | 9010-100002 NUT M10x1.25 | NUT M10x1.25 | 6 | $3.44 | Available to order | 6 |
| 20 | 30903-0201610 COTTER PIN 2.0x16 | COTTER PIN 2.0x16 | 6 | $2.29 | Available to order | 6 |
| 21 | 30006-102050810 BOLT M10x1.25x50 | BOLT M10x1.25x50 | 6 | $2.29 | Available to order | 6 |
| 22 | 7020-050400 UPPER A ARM, LH | UPPER A ARM, LH | 1 | $131.99 | Obsolete | View Details |
| 23 | 7020-050701 STEERING KNUCKLE, LH | STEERING KNUCKLE, LH | 1 | $91.99 | Available to order | 1 |
| 24 | 9DSV-050210-6K01 FRONT LOWER SWING ARM, LH | FRONT LOWER SWING ARM, LH | 1 | — | Obsolete | View Details |
| 25 | 901B-040023 FRONT PROTECTOR(LH) | FRONT PROTECTOR(LH) | 1 | $45.99 | Obsolete | View Details |
