F06-1-B — REAR SUSPENSION(CASTING)
Parts (25)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 01 | 9AWA-060110-20000 REAR SWING ARM, LH | REAR SWING ARM, LH BLACK | 1 | $450.99 | Obsolete | View Details |
| 02 | 9AWA-060109 BEARING, SWING ARM | BEARING, SWING ARM | 1 | $45.99 | Available to order | 1 |
| 03 | 9AWA-060106 OIL SEAL | OIL SEAL 24x38x8 | 1 | $5.74 | Available to order | 1 |
| 04 | 9AWA-060105-10000 DUST COVER | DUST COVER | 1 | $4.59 | Available to order | 1 |
| 05 | 9AWA-060102 BUSHING, SWING ARM | BUSHING, SWING ARM | 1 | $6.89 | Available to order | 1 |
| 06 | 9AWA-060108 LOCK NUT, SWING ARM | LOCK NUT, SWING ARM | 1 | $2.29 | Available to order | 1 |
| 07 | 9AWV-060103-2E00 SHAFT, REAR SWING ARM | SHAFT, REAR SWING ARM | 1 | $34.49 | Available to order | 1 |
| 08 | 9AWA-060101-10000 INNER SPACER | INNER SPACER | 1 | $11.49 | Available to order | 1 |
| 09 | 9AWA-060200-10000 REAR RH SWING ARM ASSY | REAR RH SWING ARM ASSY BLACK | 1 | $637.99 | Obsolete | View Details |
| 10 | 30228-061310 RIVET NUT | RIVET NUT M6 | 6 | $1.14 | Available to order | 6 |
| 11 | 30006-060016870 BOLT M6x16 | BOLT M6x16 M6x16 | 6 | $1.25 | Available to order | 6 |
| 13 | 9AWA-060100-10000 REAR LH SWING ARM ASSY | REAR LH SWING ARM ASSY BLACK | 1 | — | Obsolete | View Details |
| 14 | 30800-06005 CIRCLIP | CIRCLIP 60 | 6 | $5.74 | Available to order | 6 |
| 15 | 30411-03080 HUB BEARING | HUB BEARING | 1 | — | Obsolete | View Details |
| 16 | 30204-102810 NUT M10x1.25 | NUT M10x1.25 M10x1.25 | 6 | $1.25 | Available to order | 6 |
| 17 | 9AWA-044044 REAR SUSPENSION GUARD, RH | REAR SUSPENSION GUARD, RH | 1 | $10.34 | Available to order | 1 |
| 18 | 9AWA-044043 REAR SUSPENSION GUARD, LH | REAR SUSPENSION GUARD, LH | 1 | $10.34 | Available to order | 1 |
| 19 | 9010-060800-20000 SWAY BAR LINK (RH) | SWAY BAR LINK (RH) CCVI | 1 | $57.49 | Available to order | 1 |
| 20 | 9AWA-060410-10000 REAR SWAY BAR | REAR SWAY BAR | 1 | $120.99 | Obsolete | View Details |
| 21 | 7000-060003 SWAY BAR BUSHING | SWAY BAR BUSHING | 1 | $9.19 | Available to order | 1 |
| 22 | 9030-060002 RETAINING COVER | RETAINING COVER | 1 | $12.64 | Available to order | 1 |
| 23 | 3121401 GREASE ZERK M6 | GREASE ZERK M6 | 1 | $3.44 | Available to order | 1 |
| 24 | 30006-080016810 BOLT M8X16 | BOLT M8X16 M8x16 | 6 | $1.25 | Available to order | 6 |
| 25 | 9010-060700-20000 SWAY BAR LINK (LH) | SWAY BAR LINK (LH) CCVI | 1 | $57.49 | Available to order | 1 |
| 26 | 9AWA-060107 PARKING BRAKE CABLE BRACKET | PARKING BRAKE CABLE BRACKET | 1 | $11.49 | Available to order | 1 |
