F06 — REAR SUSPENSION
Parts (29)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 01 | 9010-060500 SWAY BAR | SWAY BAR | 1 | $80.49 | Out of Stock | Notify Me |
| 02 | 9010-060003 RUBBER SUPPORT | RUBBER SUPPORT | 1 | $6.89 | Obsolete | View Details |
| 03 | 9010-060002 GLAND COVER | GLAND COVER | 1 | $4.59 | Obsolete | View Details |
| 04 | 30006-080012810 BOLT | BOLT | 6 | $1.25 | Available to order | 6 |
| 05 | 9010-060800-20000 SWAY BAR LINK (RH) | SWAY BAR LINK (RH) | 1 | $57.49 | Available to order | 1 |
| 06 | 30204-102810 NUT M10x1.25 | NUT M10x1.25 | 6 | $1.25 | Available to order | 6 |
| 07 | 30006-102100840 BOLT M10×1.25×100 | BOLT M10×1.25×100 | 6 | $4.59 | Obsolete | View Details |
| 08 | 401B-060001 BUSH, REAR ROCKER ARM | BUSH, REAR ROCKER ARM | 1 | $19.54 | Obsolete | View Details |
| 09 | 401B-050001 SPACER,SHOCK ABSORBER | SPACER,SHOCK ABSORBER | 1 | $11.49 | Obsolete | View Details |
| 10 | 30006-102070810 BOLT | BOLT | 6 | $2.29 | Available to order | 6 |
| 11 | 9010-050003 CAP, BUFFERING COLLAR | CAP, BUFFERING COLLAR | 2 | $3.44 | Obsolete | View Details |
| 12 | 9010-050500 BUFFERING COLLAR | BUFFERING COLLAR | 4 | $8.04 | Available to order | 4 |
| 13 | 7020-060002 REAR SUSPENSION FENDER,RH | REAR SUSPENSION FENDER,RH | 1 | $68.99 | Obsolete | View Details |
| 14 | 30006-060016870 BOLT M6x16 | BOLT M6x16 | 6 | $1.25 | Available to order | 6 |
| 15 | 7020-060001 REAR SUSPENSION FENDER,LH | REAR SUSPENSION FENDER,LH | 1 | $68.99 | Obsolete | View Details |
| 16 | 9010-060700-1000 BALL PIN, LH | BALL PIN, LH | 1 | $45.99 | Obsolete | View Details |
| 17 | 7020-060401 REAR UPPER ARM, LH | REAR UPPER ARM, LH | 1 | $274.99 | Obsolete | View Details |
| 18 | 9010-060900 DUST CAP | DUST CAP | 2 | $6.89 | Available to order | 2 |
| 19 | 9010-0600A0 HOLDER UNIT,REAR WHEEL SHAFT | HOLDER UNIT,REAR WHEEL SHAFT | 1 | $131.99 | Obsolete | View Details |
| 20 | 3120100 GREASE ZERK | GREASE ZERK | 2 | $3.44 | Available to order | 2 |
| 21 | 9GQ0-050710 BEARING, HUB | BEARING, HUB | 1 | $57.49 | Available to order | 1 |
| 22 | 30800-05505 RETAINER 55 | RETAINER 55 | 6 | $2.29 | Available to order | 6 |
| 23 | 9010-060005 MIDDLE SPACER | MIDDLE SPACER | 2 | $17.24 | Available to order | 2 |
| 24 | 9010-060004 BUSHING | BUSHING | 2 | $10.34 | Available to order | 2 |
| 25 | 7020-061600-30000 REAR SHOCK ABSORBER | REAR SHOCK ABSORBER | 1 | $505.99 | Available to order | 1 |
| 26 | 30006-102050840 BOLT M10×1.25×50 | BOLT M10×1.25×50 | 6 | $4.59 | Obsolete | View Details |
| 27 | 401B-060301 REAR UPPER ARM, LH | REAR UPPER ARM, LH | 1 | $164.99 | Obsolete | View Details |
| 28 | 7020-060201 REAR LOWER ARM, RH | REAR LOWER ARM, RH | 1 | $274.99 | Obsolete | View Details |
| 29 | 401B-060101 REAR UPPER ARM, RH | REAR UPPER ARM, RH | 1 | $164.99 | Obsolete | View Details |
