F08-V3 — BRAKE SYSTEM
Parts (61)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 01 | 5HYV-081000-2500 HYDRAULIC BRAKE | HYDRAULIC BRAKE | 1 | $1319.99 | Obsolete | View Details |
| 02 | 9AWA-0811A0 BRAKE PAD SET | BRAKE PAD SET | 1 | — | Obsolete | View Details |
| 03 | 9AWV-081200-4000 FRONT RH BRAKE CALIPER | FRONT RH BRAKE CALIPER | 1 | $252.99 | Available to order | 1 |
| 04 | 30006-102025810 BOLT M10X1.25X25 | BOLT M10X1.25X25 M10x1.25x25 | 6 | $2.29 | Available to order | 6 |
| 05 | 0010-060010 WASHER 10 | WASHER 10 80 | 6 | $3.44 | Available to order | 6 |
| 06 | 7020-081004 BANJO BOLT | BANJO BOLT | 6 | $3.44 | Available to order | 6 |
| 07 | 30902-0401320 POP RIVET | POP RIVET 4x8 | 6 | $1.25 | Available to order | 6 |
| 08 | 30006-060016870 BOLT M6x16 | BOLT M6x16 M6x16 | 6 | $1.25 | Available to order | 6 |
| 09 | 5HY0-080004 CLIP, FRONT BRAKE LINE, RH | CLIP, FRONT BRAKE LINE, RH | 1 | $2.29 | Available to order | 1 |
| 10 | 9AWA-080001 PLASTIC CLIP | PLASTIC CLIP | 1 | $3.44 | Available to order | 1 |
| 11 | 5HYV-081020-2500 RH FRONT BRAKE FLUID HOSE | RH FRONT BRAKE FLUID HOSE | 1 | $57.49 | Available to order | 1 |
| 12 | 5HY0-080003 CLIP, FRONT BRAKE LINE, LH | CLIP, FRONT BRAKE LINE, LH | 1 | $2.29 | Available to order | 1 |
| 13 | 5HYV-081010-2500 LH FRONT BRAKE FLUID HOSE | LH FRONT BRAKE FLUID HOSE | 1 | $57.49 | Available to order | 1 |
| 14 | 9AWV-081100-4000 FRONT LH BRAKE CALIPER | FRONT LH BRAKE CALIPER | 1 | $252.99 | Available to order | 1 |
| 15 | 5HY0-080010-20000 BRAKE SWITCH ASSY | BRAKE SWITCH ASSY | 1 | $45.99 | Available to order | 1 |
| 16 | 30006-060012870 BOLT M6x12 | BOLT M6x12 M6x12 | 6 | $1.25 | Available to order | 6 |
| 17 | 5UWB-081002 BRAKE RESERVOIR HOSE 2 | BRAKE RESERVOIR HOSE 2 | 1 | $12.64 | Available to order | 1 |
| 18 | 7020-081002 PIPE CLIP | PIPE CLIP | 1 | $2.29 | Available to order | 1 |
| 19 | 5UWB-081001 BRAKE RESERVOIR HOSE 1 | BRAKE RESERVOIR HOSE 1 | 1 | $12.64 | Available to order | 1 |
| 20 | 9010-080405 CLAMP | CLAMP | 6 | $3.44 | Available to order | 6 |
| 21 | 5BW1-080150-20000 RESERVOIR ASSY | RESERVOIR ASSY | 1 | $68.99 | Available to order | 1 |
| 22 | 5UWB-030110 BRACKET, BRAKE RESERVOIR | BRACKET, BRAKE RESERVOIR | 1 | $8.04 | Available to order | 1 |
| 23 | 30006-080025810 BOLT M8X25 | BOLT M8X25 M8x25 | 6 | $1.25 | Available to order | 6 |
| 24 | 5BWB-081100-00002 MASTER CYLINDER | MASTER CYLINDER | 1 | $186.99 | Available to order | 1 |
| 25 | 5HYV-082000-1201 BRAKE PEDAL | BRAKE PEDAL | 1 | $25.29 | Available to order | 1 |
| 26 | 9060-105002 BUSHING | BUSHING | 2 | $4.59 | Out of Stock | Notify Me |
| 27 | 30306-120112 PLAIN WASHER | PLAIN WASHER 12 | 6 | $1.25 | Out of Stock | Notify Me |
| 28 | 30903-0322210 COTTER PIN | COTTER PIN 3.2x22 | 6 | $1.25 | Available to order | 6 |
| 29 | 9060-080003 RETURN SPRING | RETURN SPRING | 1 | $5.74 | Available to order | 1 |
| 30 | 5HY0-081030 REAR BRAKE LINE | REAR BRAKE LINE | 1 | $197.99 | Available to order | 1 |
| 31 | 30006-102030810 BOLT M10X30 | BOLT M10X30 M10x1.25x30 | 6 | $2.29 | Available to order | 6 |
| 32 | 5HYV-081050-2C00 REAR LH BRAKE CALIPER | REAR LH BRAKE CALIPER | 1 | — | Obsolete | View Details |
| 33 | 5HY0-0811A0 REAR BRAKE PAD | REAR BRAKE PAD | 1 | — | Obsolete | View Details |
| 34 | 5HY0-080002 CLIP, REAR BRAKE LINE | CLIP, REAR BRAKE LINE | 1 | $5.74 | Available to order | 1 |
| 35 | 5HYV-081060-2C00 REAR RH BRAKE CALIPER | REAR RH BRAKE CALIPER | 1 | — | Obsolete | View Details |
| 36 | 30202-060110 NUT M6 | NUT M6 M6 | 6 | — | Obsolete | View Details |
| 37 | 9010-080104 CIRCLIP | CIRCLIP | 6 | $5.74 | Available to order | 6 |
| 38 | 5HY0-082200-10000 PARKING BRAKE CABLE | PARKING BRAKE CABLE | 1 | $91.99 | Available to order | 1 |
| 39 | 30904-0602010 SHAFT, PIN | SHAFT, PIN 6x20 TRIVALENT CHROMIUM | 6 | $5.74 | Available to order | 6 |
| 40 | 30006-080020810 BOLT M8x20 | BOLT M8x20 M8x20 | 6 | $1.25 | Available to order | 6 |
| 41 | 5HY0-083100 PARKING BRAKE LEVER | PARKING BRAKE LEVER | 1 | — | Obsolete | View Details |
| 42 | 30303-020900 WASHER | WASHER 2 | 6 | $1.25 | Available to order | 6 |
| 43 | 30204-080810 LOCK NUT | LOCK NUT M8 | 6 | $1.25 | Available to order | 6 |
| 44 | 30903-0162010 COTTER PIN | COTTER PIN | 6 | $1.25 | Available to order | 6 |
| 45 | 7000-082210-20000 MICRO SWITCH | MICRO SWITCH | 1 | $25.29 | Available to order | 1 |
| 46 | 30105-020016700 SCREW M2X16 | SCREW M2X16 M2x16 | 6 | $1.25 | Available to order | 6 |
| 47 | 30306-020800 WASHER | WASHER 2 | 6 | $1.25 | Available to order | 6 |
| 48 | 30200-020500 NUT M2 | NUT M2 M2 | 6 | $1.25 | Available to order | 6 |
| 49 | 30110-421130010 SELF TAPPING SCREW | SELF TAPPING SCREW ST4.2x13 | 6 | $3.44 | Available to order | 6 |
| 50 | 9030-180008 RUBBERSLEEVE | RUBBERSLEEVE | 6 | $1.14 | Available to order | 6 |
| 51 | 30102-060016810 SCREW | SCREW | 6 | $1.25 | Available to order | 6 |
| 52 | 5BY0-080007 GUARD, FRONT LH BRAKE CALIPER | GUARD, FRONT LH BRAKE CALIPER | 1 | $6.89 | Available to order | 1 |
| 53 | 5BY0-080008 GUARD, FRONT RH BRAKE CALIPER | GUARD, FRONT RH BRAKE CALIPER | 1 | $6.89 | Available to order | 1 |
| 54 | 8010-000004 BOLT M6x14 | BOLT M6x14 M6x14 | 6 | $1.25 | Available to order | 6 |
| 55 | 5HYV-081100-1B00-20 DUST SEAL, PISTON | DUST SEAL, PISTON | 1 | $5.74 | Available to order | 1 |
| 56 | 5HYV-081100-1B00-21 DUST SEAL, PISTON | DUST SEAL, PISTON | 1 | — | Obsolete | View Details |
| 57 | 5HYV-081300-1B00-21 DUST SEAL, PISTON | DUST SEAL, PISTON | 1 | $5.74 | Available to order | 1 |
| 58 | 5HYV-081300-1B00-20 DUST SEAL, PISTON | DUST SEAL, PISTON | 1 | $5.74 | Out of Stock | Notify Me |
| 59 | 5HYV-081100-1B00-22 BRACKET 1 (brake pad clips) | BRACKET 1 (brake pad clips) | 1 | $3.44 | Available to order | 1 |
| 60 | 5HYV-081100-1B00-23 BRACKET 2 (brake pad clips) | BRACKET 2 (brake pad clips) | 1 | $3.44 | Available to order | 1 |
| 61 | 5HYV-080410-1C00 WIRE CLIP, OIL HOSE | WIRE CLIP, OIL HOSE | 1 | $3.44 | Available to order | 1 |
