F08 — BRAKE SYSTEM
Parts (46)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 01 | 5ASV-081000-6001 HYDRAULIC BRAKE | HYDRAULIC BRAKE | 1 | $1099.99 | Out of Stock | Notify Me |
| 02 | 9AWA-0811A0 BRAKE PAD SET | BRAKE PAD SET | 1 | — | Obsolete | View Details |
| 03 | 9AWV-081200-4000 FRONT RH BRAKE CALIPER | FRONT RH BRAKE CALIPER | 1 | $252.99 | Available to order | 1 |
| 04 | 30006-102025810 BOLT M10X1.25X25 | BOLT M10X1.25X25 M10x1.25x25 | 6 | $2.29 | Available to order | 6 |
| 05 | 0010-060010 WASHER 10 | WASHER 10 80 | 6 | $3.44 | Available to order | 6 |
| 07 | 30006-060012870 BOLT M6x12 | BOLT M6x12 M6x12 | 6 | $1.25 | Available to order | 6 |
| 08 | 5ASV-081020-6000 RH FRONT BRAKE FLUID HOSE | RH FRONT BRAKE FLUID HOSE | 1 | $73.59 | Out of Stock | Notify Me |
| 09 | 5BW1-080150-20000 RESERVOIR ASSY | RESERVOIR ASSY | 1 | $68.99 | Available to order | 1 |
| 10 | 5UWB-030110 BRACKET, BRAKE RESERVOIR | BRACKET, BRAKE RESERVOIR | 1 | $8.04 | Available to order | 1 |
| 11 | 30110-421130010 SELF TAPPING SCREW | SELF TAPPING SCREW ST4.2x13 | 6 | $3.44 | Available to order | 6 |
| 12 | 9010-080405 CLAMP | CLAMP | 6 | $3.44 | Available to order | 6 |
| 13 | 5ASV-081001-6000 FLUID RESERVOIR HOSE | FLUID RESERVOIR HOSE | 1 | $32.19 | Available to order | 1 |
| 14 | 7020-081002 PIPE CLIP | PIPE CLIP | 1 | $2.29 | Available to order | 1 |
| 15 | 5HY0-080010-20000 BRAKE SWITCH ASSY | BRAKE SWITCH ASSY | 1 | $45.99 | Available to order | 1 |
| 16 | 5ASV-081010-6000 LH FRONT BRAKE FLUID HOSE | LH FRONT BRAKE FLUID HOSE | 1 | $45.99 | Available to order | 1 |
| 17 | 5BWB-081100-00002 MASTER CYLINDER | MASTER CYLINDER | 1 | $186.99 | Available to order | 1 |
| 18 | 30006-080025810 BOLT M8X25 | BOLT M8X25 M8x25 | 6 | $1.25 | Available to order | 6 |
| 19 | 9AWV-081100-4000 FRONT LH BRAKE CALIPER | FRONT LH BRAKE CALIPER | 1 | $252.99 | Available to order | 1 |
| 20 | 5BY0-080010 FIXED BRACKET, FOOT PEDAL | FIXED BRACKET, FOOT PEDAL | 1 | $45.99 | Available to order | 1 |
| 21 | 9060-105002 BUSHING | BUSHING | 2 | $4.59 | Out of Stock | Notify Me |
| 22 | 30903-0322210 COTTER PIN | COTTER PIN 3.2x22 | 6 | $1.25 | Available to order | 6 |
| 23 | 30306-120112 PLAIN WASHER | PLAIN WASHER 12 | 6 | $1.25 | Out of Stock | Notify Me |
| 24 | 9060-080003 RETURN SPRING | RETURN SPRING | 1 | $5.74 | Available to order | 1 |
| 25 | 5ASV-082000-6000 BRAKE PEDAL ASSY | BRAKE PEDAL ASSY | 1 | $42.54 | Out of Stock | Notify Me |
| 26 | 5ASV-081030-6001 REAR BRAKE FLUID HOSE | REAR BRAKE FLUID HOSE | 1 | $63.24 | Available to order | 1 |
| 27 | 7020-0810A0 REAR BRAKE PAD | REAR BRAKE PAD | 1 | — | Obsolete | View Details |
| 28 | 5BWB-081300-10000 BRAKE CALIPER | BRAKE CALIPER | 1 | $329.99 | Obsolete | View Details |
| 29 | 30006-102030810 BOLT M10X30 | BOLT M10X30 M10x1.25x30 | 6 | $2.29 | Available to order | 6 |
| 30 | 30102-060016810 SCREW | SCREW | 6 | $1.25 | Available to order | 6 |
| 31 | 5BWB-081200-10000 REAR BRAKE CALIPER | REAR BRAKE CALIPER | 1 | $329.99 | Obsolete | View Details |
| 32 | 5HY0-083100 PARKING BRAKE LEVER | PARKING BRAKE LEVER | 1 | — | Obsolete | View Details |
| 33 | 7000-082210-20000 MICRO SWITCH | MICRO SWITCH | 1 | $25.29 | Available to order | 1 |
| 34 | 30306-020800 WASHER | WASHER 2 | 6 | $1.25 | Available to order | 6 |
| 35 | 30303-020900 WASHER | WASHER 2 | 6 | $1.25 | Available to order | 6 |
| 36 | 30200-020500 NUT M2 | NUT M2 M2 | 6 | $1.25 | Available to order | 6 |
| 37 | 30903-0162520 PIN | PIN 1.6x25 | 6 | $1.25 | Available to order | 6 |
| 38 | 30204-080810 LOCK NUT | LOCK NUT M8 | 6 | $1.25 | Available to order | 6 |
| 39 | 30006-080020810 BOLT M8x20 | BOLT M8x20 M8x20 | 6 | $1.25 | Available to order | 6 |
| 40 | 30904-0602010 SHAFT, PIN | SHAFT, PIN 6x20 TRIVALENT CHROMIUM | 6 | $5.74 | Available to order | 6 |
| 41 | 30105-020016700 SCREW M2X16 | SCREW M2X16 M2x16 | 6 | $1.25 | Available to order | 6 |
| 42 | 9030-180008 RUBBERSLEEVE | RUBBERSLEEVE | 6 | $1.14 | Available to order | 6 |
| 43 | 9010-080104 CIRCLIP | CIRCLIP | 6 | $5.74 | Available to order | 6 |
| 44 | 5ASV-083100-6002 PARKING CABLE | PARKING CABLE | 1 | $80.49 | Available to order | 1 |
| 45 | 30006-060016870 BOLT M6x16 | BOLT M6x16 M6x16 | 6 | $1.25 | Available to order | 6 |
| 46 | 6KM#-080002-8000 RUBBER OIL HOSE CLIP | RUBBER OIL HOSE CLIP | 1 | $2.29 | Available to order | 1 |
| 47 | A000-050015 CLAMP, FRONT BRAKE HOSE | CLAMP, FRONT BRAKE HOSE | 1 | $1.25 | Available to order | 1 |
