LUBRICATING SYSTEM
Parts (35)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 77338005100 Oil Filter 07 | Oil Filter 07 | 1 | $10.99 | Available to order | 1 |
| 2 | 07703305178 O-RING 33,05X1,78 | O-RING 33,05X1,78 | 1 | $3.99 | Available to order | 1 |
| 3 | 77338041200 OIL FILTER COVER 08 | OIL FILTER COVER 08 | 1 | $13.74 | Available to order | 1 |
| 4 | 0025060166 HH collar screw M6x16 TX30 | HH collar screw M6x16 TX30 | 5 | $3.99 | Available to order | 5 |
| 5 | 0799060000 TAB WASHER DIN6799-RS 6,0 | TAB WASHER DIN6799-RS 6,0 | 1 | $2.99 | Available to order | 1 |
| 6 | 58038007755 STOP DISK 8,1 X 15 X 0,5 | STOP DISK 8,1 X 15 X 0,5 | 1 | $2.99 | Available to order | 1 |
| 7 | 79438001019 OIL PUMP SPROCKET 19T | OIL PUMP SPROCKET 19T | 1 | $7.14 | Available to order | 1 |
| 8 | 0025060166S HH collar screw M6x16 TX30 SL | HH collar screw M6x16 TX30 SL | 2 | $2.99 | Available to order | 2 |
| 9 | 79438003000 OIL PUMP COVER | OIL PUMP COVER | 1 | $17.04 | Available to order | 1 |
| 10 | 59038011112 OILPUMP ROTOR-SET 12MM CPL. | OILPUMP ROTOR-SET 12MM CPL. | 1 | $24.41 | Available to order | 1 |
| 11 | 79438002000 OIL PUMP SHAFT | OIL PUMP SHAFT | 1 | $58.51 | Available to order | 1 |
| 12 | 0402251980 NEEDLEROL.DIN5402 NRA 2,5X19,8 | NEEDLEROL.DIN5402 NRA 2,5X19,8 | 1 | $1.99 | Available to order | 1 |
| 13 | 0402251180 NEEDLE ROLLER DIN5402 2,5X11,8 | NEEDLE ROLLER DIN5402 2,5X11,8 | 1 | $1.99 | Available to order | 1 |
| 14 | 0402041580 needle roller NRB 4x15.8 G2 | needle roller NRB 4x15.8 G2 | 1 | $2.99 | Available to order | 1 |
| 15 | 61238011100 ROTOR SET 22MM | ROTOR SET 22MM | 1 | $20.55 | Available to order | 1 |
| 16 | 0770440020 O-RING 44,00X2,00 VITON | O-RING 44,00X2,00 VITON | 1 | $3.99 | Available to order | 1 |
| 17 | 79438004100 OIL PUMP COVER | OIL PUMP COVER | 1 | $79.08 | Available to order | 1 |
| 18 | 58038022000 CU-seal ring DIN7603-12X18X1.5 | CU-seal ring DIN7603-12X18X1.5 | 2 | $2.99 | Available to order | 2 |
| 19 | 58030021000 OILDRAIN PLUG W.MAG. M 12X1,5 | OILDRAIN PLUG W.MAG. M 12X1,5 | 1 | $13.30 | Available to order | 1 |
| 20 | 07701250151 O-RING 12,5X1,5 VITON V75 | O-RING 12,5X1,5 VITON V75 | 2 | $4.99 | Available to order | 2 |
| 21 | 59038016100 OIL SCREEN | OIL SCREEN | 1 | $8.24 | Available to order | 1 |
| 22 | 0770020170 O-RING 17,17X1,78 GLO | O-RING 17,17X1,78 GLO | 1 | $2.99 | Available to order | 1 |
| 23 | 59038017100 PLUG M20X1,5 WS=13 | PLUG M20X1,5 WS=13 | 1 | $9.23 | Available to order | 1 |
| 24 | 0401090003 BALL DIN5401-9 | BALL DIN5401-9 | 1 | $2.99 | Available to order | 1 |
| 25 | 79438026000 PRESSURE SPRING | PRESSURE SPRING | 1 | $2.99 | Available to order | 1 |
| 27 | 78036024000 PLUG SCREW SAS M12X1,5 | PLUG SCREW SAS M12X1,5 | 1 | $11.43 | Available to order | 1 |
| 28 | 78138015001 OIL SCREEN CPL. | OIL SCREEN CPL. | 1 | $41.13 | Available to order | 1 |
| 29 | 0770012021 O-RING 12X2 VITON GREEN | O-RING 12X2 VITON GREEN | 1 | $2.99 | Available to order | 1 |
| 30 | 0770125015 O-RING 12,5X1,5 NBR | O-RING 12,5X1,5 NBR | 1 | $2.99 | Available to order | 1 |
| 31 | 0770170200 O-RING 17,00X2,00 | O-RING 17,00X2,00 | 1 | $2.99 | Available to order | 1 |
| 32 | 79438001010 NEEDLE BEARING INNER RING | NEEDLE BEARING INNER RING | 1 | $10.33 | Available to order | 1 |
| 33 | 79438001033 IDLER WHEEL 33T | IDLER WHEEL 33T | 1 | $14.18 | Available to order | 1 |
| 34 | 0988162205 THRUST WASH. DIN0988-16X22X0,5 | THRUST WASH. DIN0988-16X22X0,5 | 1 | $2.99 | Backorder — Restocking | 1 |
| 35 | 0471150010 CIRCLIP DIN0471-15X1 | CIRCLIP DIN0471-15X1 | 1 | $2.99 | Available to order | 1 |
| 99 | 79438015010 OILFILTER SERVICEKIT SX-F | OILFILTER SERVICEKIT SX-F | — | $67.31 | Available to order | 1 |
