Rear Wheel/Final Drive
Parts (39)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2010231 Wheel assembly | Wheel assembly » 55071 | 1 | $810.26 | Obsolete | View Details |
| 1 | T2010251 Wheel assembly | Wheel assembly 55072 » Black | 1 | $972.99 | Obsolete | View Details |
| 2 | 3800016-T0301 Ball bearing | Ball bearing | 1 | $45.12 | Available to order | 1 |
| 3 | 3800017-T0301 Ball bearing | Ball bearing | 1 | $45.12 | Available to order | 1 |
| 4 | T2012051 Spacer inner | Spacer inner | 1 | $27.83 | Backorder — Late July 2026 | 1 |
| 5 | 3500013-T0301 Circlip, Rear Wheel | Circlip, Rear Wheel | 1 | $3.01 | Available to order | 1 |
| 6 | 3600021-T0301 Seal | Seal | 1 | $5.60 | Available to order | 1 |
| 7 | T2012211 Cush rubber | Cush rubber | 1 | $114.08 | Available to order | 1 |
| 8 | T2012115 Sprocket carrier assembly | Sprocket carrier assembly » 51479 | 1 | $344.62 | Obsolete | View Details |
| 8 | T2012116 Sprocket carrier assembly | Sprocket carrier assembly 51480 » Black | 1 | $81.21 | Backorder — Late July 2026 | 1 |
| 9 | 3800018-T0301 Ball bearing | Ball bearing | 1 | $45.12 | Available to order | 1 |
| 10 | 3600022-T0301 Seal | Seal | 1 | $5.14 | Out of Stock | Notify Me |
| 11 | T2012108 Stud, Sprocket Carrier | Stud, Sprocket Carrier | 5 | $1.13 | Available to order | 5 |
| 12 | T2012092 Spacer, Internal | Spacer, Internal | 1 | $22.72 | Available to order | 1 |
| 13 | T2010040 Sprocket | Sprocket 40T 71699 », 4 cyl, Except CH | 1 | $53.84 | Available to order | 1 |
| 13 | T2010042 Sprocket, 42T | Sprocket, 42T 42T Check original tooth count | 1 | $53.84 | Available to order | 1 |
| 13 | T2010043 Sprocket | Sprocket 43T Check original tooth count | 1 | $53.84 | Backorder — Early August 2026 | 1 |
| 13 | T2010044 Sprocket, Rear, 44T | Sprocket, Rear, 44T 44T Check original tooth count | 1 | $50.42 | Available to order | 1 |
| 13 | 2010045-T0301 Sprocket | Sprocket 45T Check original tooth count | 1 | $42.20 | Obsolete | View Details |
| 13 | T2010046 Sprocket | Sprocket 46T Check original tooth count | 1 | $113.71 | Out of Stock | Notify Me |
| 14 | T3350234 Locknut, Flgd, M12 x 1.25 | Locknut, Flgd, M12 x 1.25 | 5 | $6.07 | Available to order | 5 |
| 15 | T2010332 Chain | Chain 110 Link Check original link count | 1 | $250.39 | Available to order | 1 |
| 15 | T2017275 530 Chain, 110L, Spares Kit | 530 Chain, 110L, Spares Kit | 1 | $195.63 | Available to order | 1 |
| 15 | T2010333 Chain | Chain 112 Link Check original link count | 1 | $246.79 | Obsolete | View Details |
| 15 | T2017285 530 Chain, 112L, Spares Kit | 530 Chain, 112L, Spares Kit | 1 | $183.18 | Backorder — Early August 2026 | 1 |
| 16 | T2010069 Spindle assy | Spindle assy » 124755 | 1 | $95.04 | Backorder — Late July 2026 | 1 |
| 16 | T2010061 Spindle assy | Spindle assy 124756 » | 1 | $94.11 | Out of Stock | Notify Me |
| 17 | 2012073-T0301 Spacer lh | Spacer lh | 1 | $4.67 | Obsolete | View Details |
| 18 | 3500010-T0301 Retaining ring | Retaining ring | 2 | $2.25 | Available to order | 2 |
| 19 | T2012053 Spacer, RH, R/Wheel | Spacer, RH, R/Wheel | 1 | $23.08 | Available to order | 1 |
| 20 | 2056001-T0301 Bolt special | Bolt special » 39103 | 1 | $30.30 | Obsolete | View Details |
| 20 | T2056020 Bolt special | Bolt special 39104 » | 1 | $28.29 | Obsolete | View Details |
| 21 | T3555032 Washer, 17 x 30 x 3 | Washer, 17 x 30 x 3 M14 | 1 | $3.17 | Available to order | 1 |
| 22 | 3600023-T0301 O ring | O ring | 1 | $1.27 | Available to order | 1 |
| 23 | T3450012 Cap | Cap 124756 » M6 | 1 | $0.84 | Available to order | 1 |
| 24 | T2017460 Chain & Sprocket Kit, 110/43/17 | Chain & Sprocket Kit, 110/43/17 3 Cyl | 1 | $274.57 | Backorder — Mid August 2026 | 1 |
| 24 | T2017470 Chain & Sprocket Kit, 110/44/18 | Chain & Sprocket Kit, 110/44/18 4 Cyl - > 36893 | 1 | $274.57 | Available to order | 1 |
| 24 | T2017480 Chain & Sprocket Kit, 110/42/18 | Chain & Sprocket Kit, 110/42/18 4 Cyl - 36894 > 71698 | 1 | $274.57 | Out of Stock | Notify Me |
| 24 | T2017490 Chain & Sprocket Kit, 110/40/19 | Chain & Sprocket Kit, 110/40/19 4 Cyl - 71699 > | 1 | $274.57 | Available to order | 1 |
