F17 — HYDRAULIC BRAKE (REAR)
Parts (35)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 01 | 6050-080271 CUSHION MAT | CUSHION MAT | 2 | $3.44 | Obsolete | View Details |
| 02 | 6050-080290 BRAKE PAD | BRAKE PAD | 1 | $26.44 | Obsolete | View Details |
| 03 | 30202-060140 NUT M6 | NUT M6 | 6 | $1.25 | Obsolete | View Details |
| 04 | 30201-060310 NUT M7 | NUT M7 | 6 | $1.14 | Obsolete | View Details |
| 05 | 30302-060140 WASHER | WASHER | 6 | $1.14 | Obsolete | View Details |
| 06 | 30300-060142 WASHER | WASHER | 6 | $2.29 | Obsolete | View Details |
| 07 | 6050-080256 ADJUSTING ROD | ADJUSTING ROD | 1 | $2.29 | Obsolete | View Details |
| 08 | 6050-080265 RECTANGULAR SEAL | RECTANGULAR SEAL | 2 | $2.29 | Obsolete | View Details |
| 09 | 5190-080155 COVER, BLEED BOLT | COVER, BLEED BOLT | 6 | $1.14 | Obsolete | View Details |
| 10 | 5190-080154 BLEED BOLT | BLEED BOLT | 6 | $2.29 | Obsolete | View Details |
| 11 | 6050-080272 MAIN SLIDE SHAFT | MAIN SLIDE SHAFT | 1 | $2.29 | Obsolete | View Details |
| 12 | 6050-080273 RUBBER COLLAR, MAIN SLIDE SHAFT | RUBBER COLLAR, MAIN SLIDE SHAFT | 6 | $1.14 | Obsolete | View Details |
| 13 | 6050-080268 COLLAR | COLLAR | 1 | $3.44 | Obsolete | View Details |
| 14 | 30006-080035810 BOLT M8x35 | BOLT M8x35 ARMY GREEN | 6 | $1.25 | Available to order | 6 |
| 15 | 6050-080274 RUBBER COLLAR, SECONDARY SLIDING SHAFT | RUBBER COLLAR, SECONDARY SLIDING SHAFT | 1 | $1.14 | Obsolete | View Details |
| 16 | 6050-080275 SECONDARY SLIDING SHAFT | SECONDARY SLIDING SHAFT | 1 | $2.29 | Obsolete | View Details |
| 17 | 30102-080050870 INNER HEX SCREW M8x50 | INNER HEX SCREW M8x50 | 6 | $2.29 | Available to order | 6 |
| 18 | 6050-080250 LOWER PUMP, REAR BRAKE | LOWER PUMP, REAR BRAKE | 1 | $80.49 | Obsolete | View Details |
| 19 | 6050-080210 REAR BRAKE PUMP COMP. | REAR BRAKE PUMP COMP. | 1 | $91.99 | Obsolete | View Details |
| 20 | 5190-080104 SEAL WASHER | SEAL WASHER | 2 | $2.29 | Available to order | 2 |
| 21 | 6050-080005 PIPE CLIP | PIPE CLIP | 1 | $2.29 | Obsolete | View Details |
| 22 | 5190-080108 OIL FILLING BOLT | OIL FILLING BOLT | 6 | $2.29 | Obsolete | View Details |
| 23 | 6050-080230 REAR BRAKING PIPE COMP. | REAR BRAKING PIPE COMP. | 1 | $57.49 | Obsolete | View Details |
| 24 | 30006-060025810 BOLT | BOLT ARMY GREEN | 6 | $3.44 | Available to order | 6 |
| 25 | 6050-080103 CLAMP | CLAMP | 6 | $3.44 | Obsolete | View Details |
| 26 | 30105-040010410 SCREW, M4x10 | SCREW, M4x10 | 6 | $1.14 | Obsolete | View Details |
| 27 | 30303-040142 WASHER | WASHER | 6 | $1.14 | Obsolete | View Details |
| 28 | 30304-040410 WASHER 4 | WASHER 4 | 6 | $2.29 | Obsolete | View Details |
| 29 | 5190-080225 BRAKE LIGHT SWITCH | BRAKE LIGHT SWITCH | 1 | $9.19 | Obsolete | View Details |
| 30 | 30204-060810 NUT M6 | NUT M6 | 6 | $1.25 | Available to order | 6 |
| 31 | 5190-080127 BOLT | BOLT | 6 | $1.14 | Obsolete | View Details |
| 32 | 5190-080126 SEMI-COVER | SEMI-COVER | 1 | $3.44 | Obsolete | View Details |
| 33 | 5190-080124 BOLT | BOLT | 6 | $2.29 | Obsolete | View Details |
| 34 | 5190-080223 BRAKE LEVER | BRAKE LEVER | 1 | $17.24 | Obsolete | View Details |
| 35 | 6050-080200 REAR HYDRAULIC BRAKE ASSY. | REAR HYDRAULIC BRAKE ASSY. | 1 | $164.99 | Obsolete | View Details |
